Sonca · Mini dumper
Mini dumper SJ-08EL
Tracked mini dumper, high capacity.
In stock6 950 €excl. VAT
i.e. 8 340 € incl. VAT
800 kg
Operating weight
0.22 m³
Skip capacity
10 hp
Engine power
1.75 m
Tipping height
✓ 2-year warranty✓ Delivery across France✓ Direct importer
The SONCA SJ-08EL is a tracked mini dumper with a tipping skip, designed to carry soil, rubble and materials over the most difficult terrain. Its large capacity makes it a valuable ally for clearance and landscaping sites. Imported directly by CZN Machinery, 2-year warranty, delivery across France.
10 hp diesel engine and all-terrain tracks
10 hp KD292F diesel engine (306 cc) with electric start and rugged tracks to carry heavy loads over rough, muddy or sloping ground up to 20°.
10 hp KD292F engine
306 cc, electric start, high torque.
Rugged tracks
Stability and grip on all terrain, 20° gradient.
0.22 m³ skip
Total volume 0.26 m³, tipping height 1.75 m.
Compact, telescopic and easy to service
1.98 × 0.87 × 1.68 m format and telescopic design for confined spaces. Cover-free design giving easy access to components and servicing.
Compact dimensions
1.98 m × 0.87 m × 1.68 m, 2 speeds (2.1-4.2 km/h).
Oil cooler
Optimised heat dissipation for intensive use.
Simplified servicing
7 L hydraulic tank, easy access to components.
Technical specifications
General specifications
- Operating weight
- 800 kg
- Machine length
- 1,982 mm
- Machine width
- 870 mm
- Machine height
- 1,680 mm
- Distance between track centres
- 620 mm
- Skip dimensions
- 1235 × 730 × 590 mm
- Climbing capacity
- 20°
Working performance
- Skip volume
- 0.26 m³
- Loading capacity
- 0.22 m³
- Lift and tipping height
- 1,750 mm
- Travel speed
- 2.1 - 4.2 km/h
- Number of speeds
- 2 speeds
- Travel system
- Tracks
Drivetrain & engine
- Engine
- KD292F Diesel 10 hp
- Displacement
- 306 cc
- Power
- 10 hp
- Fuel
- Diesel
- Start
- Electric
- Fuel tank
- 5.3 L
- Hydraulic tank
- 7 L
